Replacing Corotrons
Replacing the corotron — overview
Attention:
■
Corotrons can only be replaced when printing is stopped.
■
Corotrons may only be used for the purpose for which they were originally intended.
■
If the corotron had a short service life, the cause of the damage must be clarified in
order to prevent further damage.
■
When replacing a corotron, always wear the gloves provided. Ensure that you do not
touch or damage the corotron wires.
Overview
#
NoteSee sectionExpendable
The procedure is the
same for the upper and
the lower print unit.
‘Removing the cleaning corotron
slide-in unit or charge corotron
slide-in unit of the photoconductor
unit’ on page 413
Cleaning corotron of
the photoconductor
unit
Charge corotron of the
photoconductor unit
‘Removing the cleaning corotron
slide-in unit of the transfer unit’
on page 418
Cleaning corotron of
the transfer unit
A reload corotron is
only used in the upper
print unit.
‘Removing the reload corotron
slide-in unit of the transfer unit’
on page 421
Reload corotron of the
transfer unit
A recharge corotron is
only used in the lower
print unit.
‘Removing the recharge corotron
slide-in unit of the transfer unit’
on page 425
Recharge corotron of
the transfer unit
The procedure for replacing a corotron wire is the same for all corotrons: ‘Replacing
corotron wire’ on page 428.
Chapter 9 - Replacing Expendables412
Replacing the corotron — overview
