Paper
Note:
The paper specifications (see ‘Other Documents’ on page 27) contain exact information
on the permissible papers. The most important paper requirements are listed below.
Requirements
#
PinlessPaper transport
Single ply, with or without guide holes, perforated, color or
pre-printed
Continuous paper
Roller, stack, high stackPaper input
#
165–482.6 mm (6.5–19 inches)Print width
165–495.3 mm (6.5–19.5 inches)Format width
Note
If a 19" application is printed on a 19.5" paper web, then an
unprinted border of 0.5" is always left on the right-hand side,
rather than a 0.25" border on both sides.
For example:
76.2–1371.6 mm (3–54 inches)
Notes:
■
In special cases, a switch to 1524 mm (60") is possible after
successful testing by Service.
■
Format heights between 762–1016 mm (30–40 inches) are
not supported.
Format height in
mode 1/1–4/4
Appendix A - Technical Data496
Paper
