Replacing the Photoconductor Belt in the Lower
Print Unit
Removing Photoconductor Belt in Lower Print Unit and Re-
placing Photoconductor Blade.
Attention:
Observe the safety directives in the ‘Replacing the Belt — Overview’ on page 350 section.
To Remove the Photoconductor Belt in the Lower Print Unit and Replace the
Photoconductor Blade
#
Proceed as follows:
If the printing system has not yet stopped, click the 'Stop' button.1.
On the operator panel, select the following menus and elements:
■
'Replace consumables' Menu-> 'Replace belt'
■
'Select print unit': 'Lower print unit'
■
'Select assembly': 'Photoconductor unit'
■
'Select action to be executed': 'Replace belt'
■
Click the 'Next' button.
2.
Click the 'OK' button to start the photoconductor belt replacement.
The replacement of the photoconductor belt is being prepared. The developer
stations are swiveled off.
For information on the icons displayed on the operator panel under 'Steps': see
‘Explanation of icons’ on page 134.
3.
