Proceed as follows:
■
Slip the green tube with the
transfer belt onto the transfer
unit where it is marked in
green, then pull the transfer
belt forward again to the edge
of the tube.
■
Slip the red tube onto the
transfer unit at the lower red
point.
3.
Remove the empty red tube
from packaging and slip it onto
the transfer unit at the lower red
point.
4.
■
Push the sliding foil between
the transfer belt and the low-
er red tube.
■
Pull the sliding foil up until
it wraps around the lower red
tube.
5.
Chapter 9 - Replacing Expendables 403
Inserting the Transfer Belt in the Lower Print Unit
