Proceed as follows:
Align the sliding foil so that the
edge of the transfer belt is visible
in the center of the two viewing
windows.
6.
Open the insertion tool.7.
Push the sliding foil between the
transfer belt and the green tube.
The sliding foil must completely
wrap around the green tube and
the insertion tool must be cen-
tered between the tubes.
8.
Chapter 9 - Replacing Expendables404
Inserting the Transfer Belt in the Lower Print Unit
