Proceed as follows:
Push the sliding foil in until the
edge of the transfer belt is posi-
tioned between the four emboss-
ing marks.
9.
Close the insertion tool, thereby lowering it to the transfer belt.10.
Holding the insertion tool with
your left hand and the lower
sliding foil with your right hand,
evenly and carefully push the
transfer belt onto the transfer
unit until the control LED turns
green.
11.
Remove all three tubes from the transfer unit and place them in the original
packaging.
12.
Note
Keep the tubes. You can use them to insert a used but undamaged transfer
belt at a later date, if necessary.
Chapter 9 - Replacing Expendables 405
Inserting the Transfer Belt in the Lower Print Unit
