Proceed as follows:
Hold the insertion tool with
both hands and carefully move
it in the direction of the arrow
up to the mark (white arrow).
The control LED must turn
green.
13.
Slowly pull out the insertion tool
with the upper sliding foil.
14.
Carefully pull out the lower
sliding foil.
The gloves are no longer re-
quired.
15.
Chapter 9 - Replacing Expendables406
Inserting the Transfer Belt in the Lower Print Unit
