Proceed as follows:
Open handle on the locking flap
shown.
7.
Fold locking flap upwards.
The locking flap locks into posi-
tion automatically when it has
been folded up far enough.
8.
Pull the reload corotron handle
and swivel the reload corotron
upwards.
9.
Chapter 9 - Replacing Expendables378
Removing the Transfer Belt in the Upper Print Unit - Preparation
