Proceed as follows:
Push the sliding foil between the
transfer belt and the lower red
tube.
6.
Pull the sliding foil up until it
wraps around the two red tubes.
7.
Align the sliding foil so that the
edge of the transfer belt is visible
in the center of the two viewing
windows.
8.
Chapter 9 - Replacing Expendables 387
Insert the Transfer Belt in the Upper Print Unit
