DescriptionLevel
The photoconductor belt is cleaned.4
Transfer is from the transfer belt to the paper web. In double-sided print
operation, the upper and the lower printed page are transferred at the
same time.
■
Single color printing: Black/White Printing System
For single color printing, the inked image pattern is transferred from
the transfer belt to the paper web. The transfer roller point remains
swiveled onto the paper web and paper transport is not stopped.
■
Color collection mode: Full-color or CustomTone printing system
The colored image patterns for the individual colors are first collected
on the transfer belt and then transferred together to the paper web.
During the collection process, the transfer roller point is swiveled off
from the paper web and paper transport is stopped (Start/Stop oper-
ation).
5
Example: Color collection mode in a full color printing system with
CustomTone as the fifth color
The transfer belt is cleaned.6
The inked paper is fused to the paper via infrared radiation in the fuser
module (simultaneously for single and double-sided printing).
7
Chapter 3 - Description of the Printing System 65
Printing method
