Action
2 Touch [Unlock] to unlock the door of the print module.
3 Open the lower and upper doors of the print module.
4 Hold the side with the foam strips up and slide a
cleaning cloth over the cleaning plate.
5 Use process maintenance liquid (PML) to moisten
slightly the cleaning cloth at the right-hand side.
6 1. Lift the print belt.
2. Place the cleaning plate with the cleaning cloth
underneath the print belt in the middle of the
print belt unit.
The arrow indicates the alignment of the right-hand
side of the cleaning plate.
7 Fasten the two bolts to lock the cleaning plate.
4
Clean the inner side of the print belt
Chapter 13 - Maintain the printer
391
