Parker AC30 series User Manual

8-1 Menu Organisation
AC30V series Variable Speed Drive
Chapter 8: Menu Organisation
Menu Map
The Menu System consists of a series of menus and sub-menus organised into a “tree” structure. Navigate around the tree on the GKP using the
UP, DOWN, LEFT and RIGHT keys. Individual parameters may be present in the menu tree at more than one location. Parameters and/or
menus that are not required or are empty are automatically hidden on the GKP and web page.
MENU MAP SUMMARY
Control Screen
Setup
Quick Setup
Application
Motor Control
Control & Type
Motor Nameplate
Motor Data PMAC
Auto Restart
Autotune
SVC PMAC
Inputs and Outputs
Base IO
Option
Communications
Base Ethernet
Base Modbus
Option
Clone
Environment
Monitor
Quick Monitor
Application
Motor & Drive
Inputs and Outputs
Communications
Base Ethernet
Base Modbus
Option
Energy Meter
Trips
Favourites
Parameters
* The “Parameters” menu is intended for expert use only, see Appendix D
