1-2 Safety
AC30V series Variable Speed Drive
PERSONNEL
Installation, operation and maintenance of the equipment should be carried out by competent personnel. A competent person is someone who is
technically qualified and familiar with all safety information and established safety practices; with the installation process, operation and maintenance
of this equipment; and with all the hazards involved.
Risk of electric
shock
WARNING
Hot surfaces
Caution
Refer to documentation
Protective Conductor
Terminal
HAZARDS
DANGER! - Ignoring the following may result in injury
1. This equipment can endanger life by exposure to rotating
machinery and high voltages.
2. The equipment must be permanently earthed due to the high
earth leakage current, and the drive motor must be connected to
an appropriate safety earth.
3. Ensure all incoming supplies are isolated before working on the
equipment. Be aware that there may be more than one supply
connection to the drive.
4. There may still be dangerous voltages present at power terminals
(motor output, supply input phases, DC bus and the brake, where
fitted) when the motor is at standstill or is stopped.
5. For measurements use only a meter to IEC 61010 (CAT III or
higher). Always begin using the highest range.
CAT I and CAT II meters must not be used on this product.
6. Allow at least 5 minutes for the drive's capacitors to discharge to
safe voltage levels (<50V). Use the specified meter capable of
measuring up to 1000V dc & ac rms to confirm that less than 50V
is present between all power terminals and between power
terminals and earth.
7. Unless otherwise stated, this product must NOT be dismantled. In
the event of a fault the drive must be returned. Refer to "Routine
Maintenance and Repair".
