Parker AC30 series User Manual

4-15 Installation
AC30V Variable Speed Drive
Control Module Cover Removal
To gain access to the control wiring first remove the control module cover as follows:
1. First remove the GKP by pulling from the top down, and remove.
2. Undo the screw and slide the control module cover down slightly,
then remove.
www.comoso.com

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
