Parker AC30 series User Manual

Safe Torque Off 6-10
AC30V series Variable Speed Drive
OUTPUT SPECIFICATION
OFF state:
Maximum applied voltage: ±30V (X10/06 relative to X10/05)
Leakage current: Less than 0.1mA.
ON state:
Maximum output current: 150mA
Overcurrent protection: Included
Resistance between output terminals: Less than 6Ω.
WARNING
WIRED CONNECTIONS TO TERMINALS X10/01, X10/03, X10/05 AND X10/06 MUST BE LESS THAN 25 METRES IN LENGTH
AND REMAIN WITHIN THE CUBICLE OR DRIVE ENCLOSURE. PARKER IS NOT LIABLE FOR ANY CONSEQUENCES IF EITHER
CONDITION IS NOT MET.
www.comoso.com

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
