Parker AC30 series User Manual

Parameter Reference D-55
AC30V series Variable Speed Drive
IO Option Common
Parameters::Option IO:: Option IO
PNO Parameter Descriptions
1178 IO Option Type
Defines the type of IO option required by the configuration.
0. NONE
1. GENERAL PURPOSE
2. THERMISTOR
3. RTC AND THERMISTOR
1179 Actual IO Option
Indicates the type of IO option that is currently fitted
0. NONE
1. GENERAL PURPOSE
2. THERMISTOR
3. RTC AND THERMISTOR
1180 IO Option Status
Indicates the status of the IO option
0. OK
1. OPTION NOT FITTED
2. TYPE MISMATCH
3. TYPE UNKNOWN
4. HARDWARE FAULT
Functional Description
These parameters are used to set and verify the IO Option configuration. If the status parameter is not OK then the drive will not enter the
Operational state.
Status
Description
OK
The configuration is valid. The status will always be OK if no IO option is required, even if one is fitted. Alternatively, if
the IO option fitted is working correctly and supports the required functionality then the status will be OK
For example, if the required type is THERMISTOR and the actual type is GENERAL PURPOSE then the status will be
OK as the General Purpose option supports the thermistor functionality.
OPTION NOT FITTED
An option was required and none was detected
TYPE MISMATCH
The fitted option does not support the required features
TYPE UNKNOWN
The firmware in the drive does not recognise the fitted option
HARDWARE FAULT
The fitted option is not working as expected.
