D-56 Parameter Reference
AC30V series Variable Speed Drive
IO Values
Monitor::Inputs and Outputs
Parameters::Inputs and Outputs::IO Values
These parameters present the Input and Output values in a form suitable for processing by the application and fieldbus.
PNO Parameter Descriptions
0005 Digin Value
Presents all the digital inputs to the drive as a 16-bit word. The bits within the word may be accessed individually, or the entire
word may be accessed as a group.
Bit
Signal name
Terminal
Comment
PNO for individual bit access
0
Digital Input 01
X13.2
0006
1
Digital Input 02
X13.3
0007
2
Digital Input 03
X13.4
0008
3
Digital Input 04
X12.1
Common terminal with digital output 1
0009
4
Digital Input 05
X12.2
Common terminal with digital output 2
0010
5
Digital Input 06
X12.3
Common terminal with digital output 3
0011
6
Digital Input 07
X12.4
Common terminal with digital output 4
0012
7
STO Inactive
X10
0013
8
Digital Input 11
X20.1
GPIO option
0014
9
Digital Input 12
X20.2
GPIO option
0015
10
Digital Input 13
X20.3
GPIO option
0016
11
Digital Input 14
X20.4
GPIO option
0017
12
Run Key
-
GKP Run key pressed*
0018
13
Not Stop Key
-
GKP Stop key not pressed*
0019
14
Stop Key
-
GKP Stop key pressed*
0020
* If the GKP is not fitted then both “Not Stop Key” and “Stop Key” will be 0. This condition may be used to detect a
disconnected GKP.
0022 Digout Value
Presents all the digital outputs from the drive as a 16-bit word. The bits within the word may be accessed individually, or the
entire word may be accessed as a group.
Bit
Signal Name
Terminal
Comment
PNO for individual bit access
0
Digital Output 01
X12.1
Common terminal with digital input 4
0023
1
Digital Output 02
X12.2
Common terminal with digital input 5
0024
2
Digital Output 03
X12.3
Common terminal with digital input 6
0025
3
Digital Output 04
X12.4
Common terminal with digital input 7
0026
4
Relay 01
X14.1&2
0027
5
Relay 02
X14.3&4
0028
8
Digital Output 11
X20.1
GPIO option
0031
9
Digital Output 12
X20.2
GPIO option
0032
10
Digital Output 13
X20.3
GPIO option
0033
11
Digital Output 14
X20.4
GPIO option
0034
14
Relay 11
X23.1 & 2
GPIO option
0037
15
Relay 12
X23.3 & 4
GPIO option
0038
