Parker AC30 series User Manual

Technical Specifications F-15
AC30V series Variable Speed Drive
DIGITAL INPUTS
DIN1 (X13/02) – DIN3 (X13/04), DIO1 (X12/01) – DIO4 (X12/04)
Conforming to EN61131-2
Nominal Rated Voltage
24V
Operating Range
DIN1, DIN2, DIN3, DIO1, DIO2, DIO2, DIO4:
0-5V dc = OFF, 15-24V dc = ON
(absolute maximum input voltage ±30V dc)
undefined state
15V
5V
0V
24V
ON
OFF
Input Threshold
Typically 10V
Input Impedance 3.3kΩ
Input Current
7.3mA ± 10% @ 24V
Sample Interval
1ms
DIGITAL OUTPUTS
DIO1 (X12/01) – DIO4 (X12/04), conforming to EN61131-2
Nominal Open Circuit
Output Voltage
24V (minimum 21V)
Rated Output Current
140mA : The total current available is 140mA, either individually or as the sum of all digital outputs and User +24V
Supply.
Overload / Short
Circuit Protection
Indefinite
www.comoso.com

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
