D-14 Parameter Reference
AC30V series Variable Speed Drive
Clone
Setup::Clone
Parameters::Device Manager::Clone
The clone feature allows the drive configuration (application and parameters) to be saved to an SD card and subsequently loaded to the same or
a different drive.
All parameters fall into one of the following cloning categories listed in the parameter table at the end of this appendix:
• Never: This type of parameter would never be copied to a new drive. This category includes parameters that are not saved and
parameters that contain information such as runtime statistics.
• Drive Unique: This type of parameter is normally unique to the drive, such as the drive name.
• Power: This type of parameter is related to the power stack of the drive or to the motor connected to the drive.
• Other: Any saved parameter that is not in the other cloning categories. This category is the majority of the parameters including the
application parameters.
The visibility of the following cloning parameters on the GKP may depend on the selection of other cloning parameters and whether an SD card is
fitted.
PNO Parameter Descriptions
1534 Clone Filename
The filename used for saving or loading the clone file. The file extension for clone files is “.cln” and will be added to the filename if it
is not provided by the user.
A single file contains the information for the parameters and the application.
1537 Clone Direction
Sets whether a clone save or a clone load should be performed.
Enumerated Value : Clone Direction
0 : SAVE TO FILE
To Next Page
