Parker AC30 series User Manual

Technical Specifications F-3
AC30V series Variable Speed Drive
EARTHING/SAFETY DETAILS
Earthing
Permanent earthing is mandatory on all units.
• Use a copper protective earth conductor 10mm² minimum cross-section, or install a second conductor in parallel with the
protective conductor to a separate protective earth terminal
• The conductor itself must meet local requirements for a protective earth conductor
Input Supply Details
(TN) and (IT)
Drives without filters are suitable for earth referenced (TN) or non-earth referenced (IT) supplies.
The drive is only suitable for earth referenced supplies (TN) when fitted with an internal filter. External filters are available for
use on TN and IT (non-earth referenced) supplies.
Prospective Short Circuit
Current (PSCC)
Refer to the appropriate Electrical Ratings table.
Earth Leakage Current
>10mA (all models)
INTERNAL COOLING FANS
The forced-vent cooling of the drive is achieved by 1, or in some cases 2 fans. The Fan Rating gives the volume of air venting from the drive.
Product Fan Ratings
FRAME D
All models 1 off 27 cfm (45m³/hr)
FRAME E
All models 1 off 33 cfm (56m³/hr)
FRAME F
All models 2 off 27 cfm (45m³/hr)
FRAME G
All models
2 off 53 cfm (89 m³/hr)
FRAME H
45kW
2 off 27 cfm (45 m³/hr)
55 – 75kW
2 off 53 cfm (89 m³/hr)
FRAME J
All Models
2 off 27 cfm (45 m³/hr)
3 off 80 cfm (133 m³/hr)
www.comoso.com

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
