Technical Specifications F-13
AC30V series Variable Speed Drive
SUPPLY SHORT CIRCUIT RATING
The following drives when fitted with UL Listed fuses are suitable for use on a circuit capable of delivering not more than:
Frames D, E, F, G: 5,000 RMS Symmetrical Amperes, 480V maximum
Frame H: 10,000 RMS Symmetrical Amperes, 480V maximum
Frame J: 10,000 RMS Symmetrical Amperes, 480V maximum
Refer to Appendix C: “Compliance” – Solid –State Short Circuit Protection
When group installed with the specified line reactor frame D, E, F, G, H & J sizes may be used on a supply rating delivering not more than 50,000
RMS Symmetrical amperes, 480V maximum, see table below for further information:
Frame Size Motor Power Parker Part Number MTE Part Number Inductance mH Rated amps
D 1.1kW / 1.5hp CO470651 RL-00402 6.5 4
D 1.5kW / 2hp CO470651 RL-00402 6.5 4
D 2.2kW / 3hp CO352782 RL-00803 5 8
D 3kW CO352782 RL-00803 5 8
D 4kW / 5hp CO470652 RL-00802 3 8
D 5.5kW / 7.5hp CO352783 RL-01202 2.5 12
E 7.5kW / 10hp CO352785 RL-01802 1.5 18
E 11kW / 15hp CO352786 RL-02502 1.2 25
F 15kW / 20hp CO352901 RL-03502 0.8 35
F 18kW / 25hp CO352901 RL-03502 0.8 35
G 22kW / 30hp CO352902 RL-04502 0.7 45
G 30kW / 40hp CO352903 RL-05502 0.5 55
G 37kW / 50hp CO352904 RL-08002 0.4 80
H 45kW / 60hp CO352904 RL-08002 0.4 80
H 55kW / 75hp CO352905 RL10002 0.3 100
H 75kW / 100hp CO352906 RL13002 0.2 130
J 90kW / 125hp CO470057 RL-16002 0.15 160
J 110kW / 150hp CO470046 RL-20002 0.11 200
J 132kW / 200hp CO470046 RL-25002 0.09 250
