Parker AC30 series User Manual

6-3 Safe Torque Off
AC30V series Variable Speed Drive
Alignment to European Standards
EN ISO13849-1:2008
(Safety of machinery – Safety-related parts of control systems)
STO aligns internally to the following aspects of this standard:
• Architecture according to Category 3:
Solid lines represent the STO control paths.
Dashed lines represent reasonably practicable fault detection.
Key: I1, I2 = user terminal
L1, L2 = logic
O1, O2 = methods of enabling or disabling output power devices
i
mxy
= interconnecting means
m
x
= monitoring
c = cross monitoring
• Category 3 general requirements are:
A single failure, and any consequential failures, will not lead to loss of the STO safety function.
Failure of more than one component can lead to the loss of the STO safety function.
I1 L1 O1
I2 L2 O2
i
m1a
i
m2a
i
m1b
i
m2b
m
1
m
2
c
www.comoso.com

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
