Parameter Reference D-97
AC30V series Variable Speed Drive
Sequencing
Parameters::Motor Control::Sequencing
These parameters allow the user of the AC30V to monitor the status and affect the behaviour of the DS402 drive state machine as described in
detail in Appendix B “Sequencing Logic”.
PNO Parameter Descriptions
0591 Local
Local (GKP) of Control and Reference.
1565 Local Power Up Mode
The initial value of
0591 Local can be selected by the User using this enumerated parameter.
0: AS WHEN POWERED DOWN the state when the Drive was powered down (default)
1: LOCAL always powers up with
0591 Local set to TRUE
2: REMOTE always powers up with
0591 Local set to FALSE
0592 Local Reference
Local Reference from GKP.
0610 App Control Word
Control Word from Application (Terminals).
0627 Comms Control Word
Control Word from Fieldbus.
0644 Control Word
Monitor (read-only) Control Word updated from the active source.
0661 Status Word
This is the DS402 Status Word
0678 Sequencing State
Drive DS402 Sequencing State.
0679 Switch On Timeout
Time allowed for line contactor to close when entering the Switched On state from Switched Off state. If this time is non-zero, a Line
Contactor trip will occur if the DC Link Voltage remains low until the timeout expires. If the timeout is set to zero, an Under Voltage
trip will occur immediately.
0680 App Reference
Reference from terminals (via. the application)
