Technical Specifications F-1
AC30V series Variable Speed Drive
Appendix F: Technical Specifications
Understanding the Product Code
MODEL NUMBER
The unit is fully identified using a four block alphanumeric code which records how the drive was calibrated, and its various settings when
dispatched from the factory. This can also be referred to as the Product Code.
Typical example: 31V-4D0004-BF-2S0000 (as shown in the example below).
This shows the product is an
AC30V drive Frame D, IP21
standard suitable for fan and
pump industry, rated at 400
-
480 Volts supply, 1.1kW
(normal duty), with brake
switch fitted, and Category C2
EMC filter, with GKP fitted with
standard conformal coating
and no special options.
Block 2 Block 3
3 1 V - 4 D 0004 - B F - 2 S 0000
Family
IP Rating IP Rating, IP21 SD 1
IP Rating, IP54 SD 2
IP Rating, Cold Plate SD 3
IP Rating, IP21 CD 4
IP Rating, IP54 CD 5
IP Rating, Cold Plate CD 6
Industry Industry, General V
Industry, Hydraulics F
Industry, Refridgeration R
Supply voltage: 400V / 480V 4
Frame
400V 3 phase supply kW hp kW hp Size
Rating Data: 1.1 1.5 0.75 1 D D 0004
1.5 2 1.1 1.5 D D 0005
2.2 3 1.5 2 D D 0006
3 2.2 3 D D 0008
4 5 3 D D 0010
5.5 7.5 4 5 D D 0012
7.5 10 5.5 7.5 E E 0016
11 15 7.5 10 E E 0023
15 20 11 15 F F 0032
18 25 15 20 F F 0038
22 30 18 25 G G 0045
30 40 22 30 G G 0060
37 50 30 40 G G 0073
45 60 37 50 H H 0087
55 75 45 60 H H 0105
75 100 55 75 H H 0145
90 125 75 100 J J 0180
110 150 90 125 J J 0205
132 200 110 150 J J 0260
Brake Switch Not Fitted N
Brake switch fitted B
EMC filter None N
Category C3 E
Category C2 F
GKP Not Fitted 0
Blank Fitted 1
GKP Fitted 2
Conformal Coating Standard 3C3 S
Enhanced E
Special Option None 0000
