Trips & Fault Finding 10-6
AC30V series Variable Speed Drive
Runtime Alerts
A Runtime Alert is a fault that indicates a permanent hardware error. The Runtime Alert display is of the form
RUNTIME ALERT
CODE 00000000
CODE is a number in the range 0 to 65000. The following value is used to provide additional information to assist Parker Hannifin Technical
Support personnel.
Possible Reason for Error
1 to
255
Internal exception
• VCM not secured to power stack
• Option not secured correctly to VCM control card
• Earth bonding failure.
• Fault during firmware upgrade
12 Memory access
• Attempt to read or write to protected memory. Most likely this will be due to a configuration error. Press OK
several times until the drive resets correctly, then replace the configuration using PDQ.
• Record the error message and contact Technical Support
1001
to
1003
Processor overload
• Select a lower switching frequency, (Parameters::Motor Control::Pattern Generator::Stack Frequency)
• Record the error message and contact Technical Support
1006 Memory overflow
• Reduce the complexity of the application
• Reduce the number of parameters being accessed via the on board Modbus TCP protocol
• Reduce the number of parameters being accessed by the fieldbus communications option.
1007 Uninitialized pointer
• Record the error message and contact Technical Support
1010,
1101
to
1111
Initialization error
• Record the error message and contact Technical Support
1200
to
1299
Communications option
error
• Ensure the communications option is correctly fitted
• Update the firmware in the AC30.
• Replace the communications option
1300 Ethernet fault
• Record the error message and contact Technical Support
