Parker AC30 series User Manual

10-7 Trips & Fault Finding
AC30V series Variable Speed Drive
CODE
ERROR
Possible Reason for Error
1301 Modbus server
• Record the error message and contact Technical Support
1302
HTTP server fault
• Record the error message and contact Technical Support
1303 DCT server fault
• Record the error message and contact Technical Support
1401
1402
Control Module test
• Control module self-test error
1403
1404
Power stack test
• VCM not secured to power stack
• Power stack self-test error
1501
1502
1503
IO Option identity
IO Option processor
Unknown IO Option
• Ensure the IO option is correctly fitted
• Update the firmware in the AC30.
• Replace the IO option
1502 IO Option processor
• Ensure the IO option is correctly fitted
• Update the firmware in the AC30.
•
Replace the IO option
1503
Unknown IO Option
• Ensure the IO option is correctly fitted
• Update the firmware in the AC30.
• Replace the IO option
1504 IO Option watchdog
• The IO Option has become disconnected
1601 Stack internal fault
• Return the power stack to Parker Hannifin repair center.
