12-2 Ethernet
AC30V series Variable Speed Drive
STATUS MONITORING
The MAC address of the Ethernet port is fixed at the factory and can be read using the parameter
0945 MAC Address
The current IP settings of the AC30 can be monitored using the following parameters:
0926 IP Address
0927 Subnet Mask
0928 Gateway Address
The state of the Ethernet can be monitored using the parameter 0919 Ethernet State and from the Ethernet icon on the GKP status bar.
Setting the IP Address
To enable communications over the Ethernet an IP address must be set.
The IP address may be set as follows:
• Manually to a fixed address
• Automatically by a DHCP server connected on the network
• Automatically by the AC30 to a link-local address using Auto-IP (also known as Automatic Private IP Addressing)
The parameters 0929 DHCP and 0930 Auto IP are used to determine how the IP address is set. The factory default of these parameters is
TRUE.
The parameter 0936 Setting Lock, when set to TRUE, prevents a configuration tool from modifying the IP settings.
Manually Setting the IP Address
0935 User Gateway Address
Preferred Gateway Address
To set the IP address manually both the DHCP and Auto-IP must be disabled. The IP address, subnet mask and gateway address will be set
from the values in the parameters 0933 User IP Address, 0934 User Subnet Mask, 0935 User Gateway Address.
If the network does not have a gateway to another network then the gateway address may be set to 0.0.0.0
