Parker AC30 series User Manual

F-4 Technical Specifications
AC30V series Variable Speed Drive
ELECTRICAL RATINGS (400V BUILD VARIANT)
Power Supply = 380-480V ±10%, 50/60Hz ±5%
Motor power, output current and input current must not be exceeded under steady state operating conditions.
Minimum repetitive power up / power down cycle time = 10 mins
Product Code Motor Power Output Current
(A)
Input Current
(A)
Estimated
Efficiency
Switching Frequency
(kHz)
nominal / maximum
Output Current Derate %/kHz
(applied above nominal
switching frequency)
FRAME D : Input currents for kW ratings are at 400V 50Hz ac input and for Hp ratings at 460V 60Hz ac input. Prospective short circuit current
5kA.
Normal Duty (Output Overload Motoring 110% for 60s)
31V-4D0004…
1.1kW 3.5 4
95% 4 / 16 2.4%
1.5Hp 3.0 3.5
31V-4D0005…
1.5kW
4.5
5.3
96% 4 / 16 3.7%
2Hp
3.4
4.5
31V-4D0006…
2.2kW
5.5
7.6
97% 4 / 16 4.5%
3Hp 4.8 6.4
31V-4D0008…
3kW 7.5 6.5
97% 4 / 16 4.0%
31V-4D0010…
4kW
10.0
8.0
97% 4 / 16 3.9%
5Hp
7.6
6.6
31V-4D0012…
5.5kW 12.0 10.6
97% 4 / 16 3.5%
7.5Hp 11 9.4
Heavy Duty
(Output Overload Motoring 150% for 60s, 180% for 0.3s short term rating)
31V-4D0004…
0.75kW
2.5
2.9
95% 4 / 16 1.0%
1Hp
2.1
2.4
31V-4D0005…
1.1kW
3.5
4.0
95% 4 / 16 3.1%
1.5Hp
3.0
3.5
31V-4D0006…
1.5kW
4.5
5.3
96% 4 / 16 4.3%
2Hp
3.4
4.5
31V-4D0008…
2.2kW
5.5
5.2
97% 4 / 16 3.8%
3Hp
4.8
4.6
31V-4D0010…
3kW
7.5
6.5
97% 4 / 16 3.8%
31V-4D0012…
4kW
10.0
8.0
97% 4 / 16 3.3%
5Hp
7.6
6.6
www.comoso.com

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
