Parker AC30 series User Manual

Technical Specifications F-5
AC30V series Variable Speed Drive
Power Supply = 380-480V ±10%, 50/60Hz ±5%
Motor power, output current and input current must not be exceeded under steady state operating conditions.
Minimum repetitive power up / power down cycle time = 10 mins
Product Code
Motor Power
Output Current
(A)
Input Current
(A)
Estimated
Efficiency
Switching Frequency
(kHz)
nominal / maximum
Output Current Derate %/kHz
(applied above nominal
switching frequency)
FRAME E: Input currents for kW ratings are at 400V 50Hz ac input and for Hp ratings at 460V 60Hz ac input. Prospective short circuit current
5kA.
Normal Duty
(Output Overload Motoring 110% for 60s)
31V-4E0016…
7.5kW 16 14.5
97% 4 / 16 5.5%
10Hp 14 12.1
31V-4E0023…
11kW 23 20.4
97% 4 / 16 5.1%
15Hp 21 18.0
Heavy Duty
(Output Overload Motoring 150% for 30s, 180% for 0.3s short term rating)
31V-4E0016…
5.5kW 12 10.7
97% 4 / 16 4.9%
7.5Hp 11 9.5
31V-4E0023…
7.5kW 16 14.5
97% 4 / 16 4.9%
10Hp 14 12.7
FRAME F : Input currents for kW ratings are at 400V 50Hz ac input and for Hp ratings at 460V 60Hz ac input. Prospective short circuit current
5kA.
Normal Duty (Output Overload Motoring 110% for 60s)
31V-4F0032…
15kW 32 28.5
97% 4 / 12 6.3%
20Hp 27 24.5
31V-4F0038…
18.5kW 38 33.5
97% 4 / 12 6.7%
25Hp 36 30.2
Heavy Duty
(Output Overload Motoring 150% for 60s, 180% for 0.3s short term rating)
31V-4F0032…
11kW 23 21.7
97% 4 / 12 6.0%
15Hp 21 19.1
31V-4F0038…
15kW 32 28.5
97% 4 / 12 6.1%
20Hp 27 24.5
www.comoso.com

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
