Parker AC30 series User Manual

F-6 Technical Specifications
AC30V series Variable Speed Drive
Power Supply = 380-480V ±10%, 50/60Hz ±5%
Motor power, output current and input current must not be exceeded under steady state operating conditions.
Minimum repetitive power up / power down cycle time = 10 mins
Product Code
Motor Power
Output Current
(A)
Input Current
(A)
Estimated
Efficiency
Switching Frequency
(kHz)
nominal / maximum
Output Current Derate %/kHz
(applied above nominal
switching frequency)
FRAME G : Input currents for kW ratings are at 400V 50Hz ac input and for Hp ratings at 460V 60Hz ac input. Prospective short circuit current 10kA.
Normal Duty (Output Overload Motoring 110% for 60s)
31V-4G0045…
22kW
45
40
98% 3 / 12 5.7%
30Hp
40
35.7
31V-4G0060…
30kW
60
54.7
98% 3 / 12 5.9%
40Hp
52
48
31V-4G0073…
37kW 73 66.2
98% 3 / 12 5.6%
50Hp
65
58.5
Heavy Duty
(Output Overload Motoring 150% for 60s, 180% for 3s short term rating)
31V-4G0045…
18kW
38
34.3
98% 3 / 12 5.3%
25Hp
36
30.5
31V-4G0060…
22kW
45
41.8
98% 3 / 12 5.7%
30Hp
40
37.5
31V-4G0073…
30kW
60
54.7
98% 3 / 12 5.2%
40Hp
52
48
