Parker AC30 series User Manual

8-3 Menu Organisation
AC30V series Variable Speed Drive
Parameter Map
The following table shows the parameters as they appear in order on the Web page and GKP. Also shown is the Parameter Number, PNO. This
is a unique reference for each parameter. For more details about each parameter refer to Appendix D.
Control Screen
Setup
Quick Setup
Application
Motor Control
Control and Type
Motor Type
0511
Control Strategy
0512
Control Type
1533
100% Speed in RPM
0464
Acceleration Time
0486
Deceleration Time
0487
Current Limit
0305
Main Torque Lim
0417
Seq Stop Method SVC
1257
Seq Stop Method VHz
0484
Stop Ramp Time
0504
VHz Shape
0422
Fixed Boost
0447
Duty Selection
0390
Motor Nameplate
Base Frequency
0457
Rated Motor Current
0455
Motor Poles
0458
Base Voltage
0456
Nameplate Speed
0459
Power Factor
0461
Motor Power
0460
Motor Data PMAC
PMAC Max Speed
0555
PMAC Max Current
0556
PMAC Rated Current
0557
PMAC Rated Torque
0558
PMAC Motor Poles
0559
PMAC Back Emf Const KE
0560
PMAC Winding Resistance
0561
PMAC Winding Inductance
0562
PMAC Torque Const KT
0563
PMAC Motor Inertia
0564
PMAC Therm Time Const
0565
PMAC Base Volt
1387
Auto Restart
AR Enable
1469
AR Mode
1470
AR Max Restarts
1471
AR Trip Mask
1472
AR Initial Delay
1505
AR Repeat Delay
1506
Autotune
Autotune Enable
0255
Autotune Mode
0256
Nameplate Mag Current
1550
Autotune Test Disable
0257
Autotune Ramp Time
0274
ATN PMAC Test Disable
1388
ATN PMAC Ls Test Freq
1405
SVC PMAC
PMAC SVC Start Cur
0478
PMAC SVC Start Speed
0479
Inputs and Outputs
Base IO
Anin 01 Type
0001
Anin 01 Offset
0957
Anin 01 Scale
0958
Anin 02 Type
0002
Anin 02 Offset
0959
Anin 02 Scale
0960
Anout 01 Type
0003
Anout 01 Scale
0686
Anout 01 Offset
1108
Anout 01 ABS
1441
Anout 02 Type
0004
Anout 02 Scale
1460
Anout 02 Offset
1467
Anout 02 ABS
1468
