Parker AC30 series User Manual

5-9 Associated Equipment
AC30V series Variable Speed Drive
Control Terminal Cover Removal
First remove the GKP by pulling from the top down and
remove.
Undo the screw and slide the control terminal cover down,
then remove
Control Terminal Cover
INSTALLATION DETAILS
HAZARDOUS VOLTAGES may be present on GPIO module motor thermistor user relays, please refer to the option technical manual or main
product manual for safety information
www.comoso.com

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
