Associated Equipment 5-10
AC30V series Variable Speed Drive
Click the Option into place and tighten the retaining screw (as shown below).
Squeeze moulding
as shown to remove
All other options as
listed on page A-1
3 off General Purpose I/O (GPIO)
1 off Pulse Encoder
