Parker AC30 series User Manual

13-4 Fire Mode
AC30V series Variable Speed Drive
TRIPS AND AUTO RESTART
The following table summarizes which trips are disabled in the two modes of operation. Also shown are those trips which are designed to protect
the drive.
Caution Disabling the Drive Protection trips will invalidate the drive’s warranty.
Selecting PARTIAL mode leaves the drive protection features enabled. Selecting FULL mode disables some of the drive protection features.
Caution Regardless of the setting of Level, activating Fire Mode may cause damage to the motor or attached equipment.
ID
Trip Name
Disabled in Partial mode
Disabled in Full mode
Drive Protection
1
OVER VOLTAGE

2
UNDER VOLTAGE
(1)
Note 1
Note 1
3
OVER CURRENT

4
STACK FAULT

5
STACK OVER CURRENT

6
CURRENT LIMIT


7
MOTOR STALL


8
INVERSE TIME


9
MOTOR I2T


10
LOW SPEED I


11
HEATSINK OVERTEMP


12
AMBIENT OVERTEMP


13
MOTOR OVERTEMP


14
EXTERNAL TRIP


15
BRAKE SHORT CCT


16
BRAKE RESISTOR


17
BRAKE SWITCH


18
LOCAL CONTROL


19
COMMS BREAK


20
LINE CONTACTOR


21
PHASE FAIL


22
VDC RIPPLE


23
BASE MODBUS BREAK


24
24V OVERLOAD


25
PMAC SPEED ERROR


26
OVERSPEED


27
SAFE TORQUE OFF
Note 1. The Under Voltage trip is enabled when Fire Mode is active, but the trip level is reduced by 50%.
www.comoso.com

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
