Parker AC30 series - Chapter 3: Product Overview; Product Range; AC30 V Frame D, E, F, G, H

3-1 Product Overview
AC30V series Variable Speed Drive
Chapter 3: Product Overview
Product Range
AC30V FRAME D, E, F, G, H, J
Graphical Keypad
(GKP)
Integrated quick start
guide and multi-
language support
Figure 3-1
Illustrated Frame E
GPIO (General Purpose I/O Options) & Encoder
A range of field fittable I/O Options.
Control Module
Cover
Removable Fan Cassette
Can be removed for cleaning and replacement see Fan
Cassette in Chapter 11
Top Terminal Cover
Integrated Ethernet
Drive programming, monitoring and
Modbus TCP/IP COMMS
SD Card
Drive configuration storage and
application cloning
Power Stack
Fieldbus Option
A range of field-fittable
communications and I/O options
Bottom Terminal Cover
Removable Mounting
Feet
Control
Module
