Parker AC30 series User Manual

Parameter Reference D-137
AC30V series Variable Speed Drive
PNO
Name
Path(s)
Type
Default
Range
Units
WQ
View
Notes
MBus
0543
Power Stack Fitted Parameters::Device Manager::Drive info
USINT
(enum)
0:NONE
1:3.5 A 400 V
2:4.5 A 400 V
3:5.5 A 400 V
4:7.5 A 400 V
5:10.0 A 400 V
6:12.0 A 400 V
7:16.0 A 400 V
8:23.0 A 400 V
9:32.0 A 400 V
10:38.0 A 400 V
11:45.0 A 400 V R1
12:60.0 A 400 V R1
13:73.0 A 400 V R1
14:87.0 A 400 V
15:105 A 400 V
16:145 A 400 V
17:180 A 400 V
18:205 A 400 V
19:260 A 400 V
20:45.0 A 400 V
21:60.0 A 400 V
22:73.0 A 400 V
NEVER ENGINEER
01613
0555
PMAC Max Speed
Setup::Motor Control::Motor Data PMAC
Parameters::Motor Control::PMAC Motor Data
REAL 3000 0 to 100000 RPM ALWAYS TECHNICIAN 6
01637
0556
PMAC Max Current
Same as PNO 555
REAL
4.50
0.00 to 5000.00
A
ALWAYS
TECHNICIAN
6
01639
0557
PMAC Rated Current
Same as PNO 555
REAL
4.50
0.00 to 5000.00
A
ALWAYS
TECHNICIAN
6
01641
0558
PMAC Rated Torque
Same as PNO 555
REAL
4.50
0.00 to 30000.00
Nm
ALWAYS
TECHNICIAN
6
01643
0559
PMAC Motor Poles
Same as PNO 555
UINT
10
0 to 400
ALWAYS
TECHNICIAN
6
01645
0560
PMAC Back Emf Const KE
Same as PNO 555
REAL
60.0
0.0 to 30000.0
V
ALWAYS
TECHNICIAN
6
01647
0561
PMAC Winding Resistance Same as PNO 555 REAL 6.580 0.000 to 50.000 Ohm
s
ALWAYS TECHNICIAN 6
01649
0562
PMAC Winding Inductance
Same as PNO 555
REAL
20.00
0.00 to 1000.00
mH
ALWAYS
TECHNICIAN
6
01651
0563
PMAC Torque Const KT Same as PNO 555 REAL 1.00 0.00 to 10000.00
Nm/A
ALWAYS TECHNICIAN 6
01653
0564
PMAC Motor Inertia
Same as PNO 555
REAL
0.00100
0.00000 to 100.00000
kgm²
ALWAYS
TECHNICIAN
6
01655
0565
PMAC Therm Time Const
Same as PNO 555
TIME
62.000
0.000 to 10000.000
s
ALWAYS
TECHNICIAN
6
01657
0568
Magnetising Current
Parameters::Motor Control::Induction Motor Data
REAL
1.00
0.00 to 10000.00
A
ALWAYS
ENGINEER
6
01663
0569
Rotor Time Constant
Parameters::Motor Control::Induction Motor Data
TIME
0.100
0.005 to 100.000
s
ALWAYS
ENGINEER
6
01665
0570
Leakage Inductance
Parameters::Motor Control::Induction Motor Data
REAL
1.000
0.000 to 1000.000
mH
ALWAYS
ENGINEER
6
01667
0571
Stator Resistance Parameters::Motor Control::Induction Motor Data REAL 0.00 0.00 to 100.00 Ohm
s
ALWAYS ENGINEER 6
01669
0572
Mutual Inductance
Parameters::Motor Control::Induction Motor Data
REAL
100.00
0.00 to 10000.00
mH
ALWAYS
ENGINEER
6
01671
0591
Local
Parameters::Motor Control::Sequencing
BOOL
FALSE
ALWAYS
TECHNICIAN
1
01709
0592
Local Reference
Parameters::Motor Control::Sequencing
REAL
0.00
0.00 to 100.00
%
ALWAYS
OPERATOR
01711
0610
App Control Word Parameters::Motor Control::Sequencing
WORD
(bitfield)
0000
0:SWITCH ON
1:ENABLE VOLTAGE
2:NOT QUICKSTOP
3:ENABLE OPERATION
7:RESET FAULT
8:EXTERNAL FAULT
12:USE JOG REFERENCE
13:REVERSE DIRECTION
14:AUTO INITIALISE
15:EVENT TRIGGERED OP
ALWAYS ENGINEER 2
01747
