Parker AC30 series User Manual

Parameter Reference D-153
AC30V series Variable Speed Drive
PNO
Name
Path(s)
Type
Default
Range
Units
WQ
View
Notes
MBus
1494
AR Trip Mask.22 VDC RIPPLE
Same as PNO 1469
BOOL
TRUE
ALWAYS
TECHNICIAN
03515
1495
AR Trip Mask.23 BASE MODBUS BREAK
Same as PNO 1469
BOOL
TRUE
ALWAYS
TECHNICIAN
03517
1496
AR Trip Mask.24 24 V OVERLOAD
Same as PNO 1469
BOOL
TRUE
ALWAYS
TECHNICIAN
03519
1497
AR Trip Mask.25 PMAC SPEED ERROR
Same as PNO 1469
BOOL
TRUE
ALWAYS
TECHNICIAN
03521
1498
AR Trip Mask.26 OVERSPEED
Same as PNO 1469
BOOL
TRUE
ALWAYS
TECHNICIAN
03523
1499
AR Trip Mask.27 STO ACTIVE
Same as PNO 1469
BOOL
TRUE
ALWAYS
TECHNICIAN
03525
1500
AR Trip Mask.28 FEEDBACK MISSING
Same as PNO 1469
BOOL
TRUE
ALWAYS
TECHNICIAN
03527
1501
AR Trip Mask.29 INTERNAL FAN FAIL
Same as PNO 1469
BOOL
TRUE
ALWAYS
TECHNICIAN
03529
1502
AR Trip Mask.30 CURRENT SENSOR
Setup::Motor Control::Auto Restart
Parameters::Motor Control::Auto Restart
BOOL TRUE ALWAYS TECHNICIAN
03531
1503
AR Trip Mask.31 POWER LOSS STOP
Same as PNO 1502
BOOL
TRUE
ALWAYS
TECHNICIAN
03533
1505
AR Initial Delay
Same as PNO 1502
TIME
10.000
0.000 to 3600.000
s
ALWAYS
OPERATOR
03537
1506
AR Repeat Delay
Same as PNO 1502
TIME
60.000
0.000 to 3600.000
s
ALWAYS
OPERATOR
03539
1507
AR Active
Parameters::Motor Control::Auto Restart
BOOL
NEVER
OPERATOR
03541
1508
AR Restart Pending
Parameters::Motor Control::Auto Restart
BOOL
NEVER
OPERATOR
03543
1509
AR Restarts Remaining
Parameters::Motor Control::Auto Restart
USINT
0 to 20
NEVER
OPERATOR
03545
1510
AR Time Remaining
Parameters::Motor Control::Auto Restart
TIME
0.000 to 3600.000
s
NEVER
OPERATOR
03547
1511
Encoder Supply
Setup::Inputs and Outputs::Option
Parameters::Option IO::Encoder
USINT
(enum)
0
0:5 V
1:12 V
2:15 V
3:24 V
STOPPED TECHNICIAN
03549
1512
Encoder Lines
Same as PNO 1511
DINT
2048
1 to 100000
STOPPED
TECHNICIAN
03551
1513
Encoder Invert
Same as PNO 1511
BOOL
FALSE
STOPPED
TECHNICIAN
03553
1514
Encoder Type Same as PNO 1511
USINT
(enum)
0
0:QUADRATURE
1:CLOCK/DIRECTION
STOPPED TECHNICIAN
03555
1515
Encoder Single Ended
Same as PNO 1511
BOOL
FALSE
STOPPED
TECHNICIAN
03557
1516
Encoder Speed
Monitor::Inputs and Outputs
Parameters::Option IO::Encoder
REAL x. Min to Max RPM NEVER OPERATOR
03559
1517
Encoder Count Reset
Same as PNO 1511
BOOL
FALSE
ALWAYS
TECHNICIAN
2
03561
1518
Encoder Count
Same as PNO 1516
DINT
-214783648 to 214783647
NEVER
TECHNICIAN
03563
1520
Actual Rotor T Const
Parameters::Motor Control::Tr Adaptation
REAL
x.
1 to 100000
ms
NEVER
ENGINEER
03567
1521
Tr Adaptation Output
Parameters::Motor Control::Tr Adaptation
REAL
x.
1 to 500
%
NEVER
ENGINEER
03569
1526
Energy Saving Lower Lim
Parameters::Motor Control::Fluxing VHz
REAL
0.00
0.00 to 100.00
%
ALWAYS
OPERATOR
03579
1527
Max Available Volts
Parameters::Motor Control::Tr Adaptation
REAL
x.
0 to 10000
V
NEVER
ENGINEER
03581
1528
Demanded Terminal Volts
Parameters::Motor Control::Tr Adaptation
REAL
x.
0 to 1000
V
NEVER
ENGINEER
03583
1529
Terminal Volts
Parameters::Motor Control::Tr Adaptation
REAL
x.
0 to 1000
V
NEVER
ENGINEER
03585
1533
Control Type
Setup::Motor Control::Control and Type
Parameters::Motor Control::Control Mode
USINT
(enum)
0
0:SENSORLESS
1:ENCODER FEEDBACK
STOPPED TECHNICIAN 6
03593
1534
Clone Filename
Setup::Clone
Parameters::Device Manager::Clone
STRING[24] clone ALWAYS TECHNICIAN 2
03595
1537
Clone Direction Same as PNO 1534
USINT
(enum)
0
0:SAVE TO FILE
1:LOAD FROM FILE
ALWAYS TECHNICIAN 2
03601
1538
Full Restore Same as PNO 1534
USINT
(enum)
0
0:YES
1:PARTIAL
ALWAYS TECHNICIAN 2
03603
1539
Application Same as PNO 1534
USINT
(enum)
0
0:LOAD FROM FILE
1:LEAVE CURRENT APP
ALWAYS TECHNICIAN 2
03605
1540
Other Parameters Same as PNO 1534
USINT
(enum)
0
0:LOAD FROM FILE
1:LEAVE CURRENT
VALUES
2:SET TO DEFAULT
VALUES
ALWAYS TECHNICIAN 2
03607
1541
Power Parameters Same as PNO 1534
USINT
(enum)
0 Same as PNO 1540 ALWAYS TECHNICIAN 2
03609
1542
Clone Start
Same as PNO 1534
BOOL
FALSE
ALWAYS
TECHNICIAN
2
03611
