Parker AC30 series User Manual

D-148 Parameter Reference
AC30V series Variable Speed Drive
PNO
Name
Path(s)
Type
Default
Range
Units
WQ
View
Notes
MBus
1139
Control Board Up Time
Parameters::Device Manager::Runtime Statistics
UDINT
0 to Max
s
NEVER
ENGINEER
1
02805
1140
Run Key Action Parameters::Keypad::Local Control
USINT
(enum)
0
0:RUN
1:JOG
STOPPED OPERATOR
02807
1141
View Level Parameters::Keypad::Graphical Keypad
USINT
(enum)
1 Same as PNO 945 ALWAYS OPERATOR
02809
1142
GKP Password
Setup::Environment
Parameters::Keypad::Graphical Keypad
WORD 0000 ALWAYS TECHNICIAN
02811
1143
Version
Parameters::Keypad::Graphical Keypad
WORD
NEVER
OPERATOR
02813
1178
Option IO Required
Setup::Inputs and Outputs::Option
Parameters::Option IO::Option IO
USINT
(enum)
0
0:NONE
1:GENERAL PURPOSE
2:THERMISTOR
3:RTC AND THERMISTOR
4:PULSE ENCODER
CONFIG TECHNICIAN
02883
1179
Option IO Fitted Parameters::Option IO::Option IO
USINT
(enum)
Same as PNO 1178 NEVER OPERATOR 1
02885
1180
Option IO Diagnostic Parameters::Option IO::Option IO
USINT
(enum)
0:OK
1:OPTION NOT FITTED
2:TYPE MISMATCH
3:TYPE UNKNOWN
4:HARDWARE FAULT
NEVER OPERATOR
02887
1181
Anin 11 Value
Monitor::Inputs and Outputs
Parameters::Option IO::General Purpose IO
REAL x.xx -100.00 to 100.00 % NEVER OPERATOR
02889
1182
Anin 12 Value
Same as PNO 1181
REAL
x.xx
-100.00 to 100.00
%
NEVER
OPERATOR
02891
1183
Anin 13 Value
Same as PNO 1181
REAL
x.xx
-100.00 to 100.00
%
NEVER
OPERATOR
02893
1184
Thermistor Type
Setup::Inputs and Outputs::Option
Parameters::Option IO::Thermistor
USINT
(enum)
1
0:NTC
1:PTC
2:KTY
ALWAYS TECHNICIAN
02895
1185
Thermistor Resistance Parameters::Option IO::Thermistor REAL x. 0 to 5000 Ohm
s
NEVER TECHNICIAN
02897
1186
Time and Date
Parameters::Device Manager::Real Time Clock
DT
1970/01/01
1970/01/01 to 2106/02/07
ALWAYS
OPERATOR
2
02899
1187
RTC Trim
Parameters::Option IO::General Purpose IO
SINT
0
-40 to 40
ALWAYS
ENGINEER
2
02901
1188
Favourites
Parameters::Device Manager::Soft Menus
ARRAY[0..19]
ALWAYS
OPERATOR
02903
1189
Favourites[0]
Favourites
Parameters::Device Manager::Soft Menus
UINT 0000 0000 to 2149 ALWAYS OPERATOR
02905
1190
Favourites[1]
Same as PNO 1189
UINT
0000
0000 to 2149
ALWAYS
OPERATOR
02907
1191
Favourites[2]
Same as PNO 1189
UINT
0000
0000 to 2149
ALWAYS
OPERATOR
02909
1192
Favourites[3]
Same as PNO 1189
UINT
0000
0000 to 2149
ALWAYS
OPERATOR
02911
1193
Favourites[4]
Same as PNO 1189
UINT
0000
0000 to 2149
ALWAYS
OPERATOR
02913
1194
Favourites[5]
Same as PNO 1189
UINT
0000
0000 to 2149
ALWAYS
OPERATOR
02915
1195
Favourites[6]
Same as PNO 1189
UINT
0000
0000 to 2149
ALWAYS
OPERATOR
02917
1196
Favourites[7]
Same as PNO 1189
UINT
0000
0000 to 2149
ALWAYS
OPERATOR
02919
1197
Favourites[8]
Same as PNO 1189
UINT
0000
0000 to 2149
ALWAYS
OPERATOR
02921
1198
Favourites[9]
Same as PNO 1189
UINT
0000
0000 to 2149
ALWAYS
OPERATOR
02923
1199
Favourites[10]
Same as PNO 1189
UINT
0000
0000 to 2149
ALWAYS
OPERATOR
02925
1200
Favourites[11]
Same as PNO 1189
UINT
0000
0000 to 2149
ALWAYS
OPERATOR
02927
1201
Favourites[12]
Same as PNO 1189
UINT
0000
0000 to 2149
ALWAYS
OPERATOR
02929
1202
Favourites[13]
Same as PNO 1189
UINT
0000
0000 to 2149
ALWAYS
OPERATOR
02931
1203
Favourites[14]
Same as PNO 1189
UINT
0000
0000 to 2149
ALWAYS
OPERATOR
02933
1204
Favourites[15]
Same as PNO 1189
UINT
0000
0000 to 2149
ALWAYS
OPERATOR
02935
1205
Favourites[16]
Same as PNO 1189
UINT
0000
0000 to 2149
ALWAYS
OPERATOR
02937
1206
Favourites[17]
Same as PNO 1189
UINT
0000
0000 to 2149
ALWAYS
OPERATOR
02939
1207
Favourites[18]
Same as PNO 1189
UINT
0000
0000 to 2149
ALWAYS
OPERATOR
02941
1208
Favourites[19]
Same as PNO 1189
UINT
0000
0000 to 2149
ALWAYS
OPERATOR
02943
1239
Local Run Key Active
Parameters::Keypad::Local Control
BOOL
TRUE
ALWAYS
TECHNICIAN
03005
1240
Local Reverse
Parameters::Keypad::Local Control
BOOL
FALSE
ALWAYS
OPERATOR
1
03007
