Parker AC30 series User Manual

Ethernet 12-5
AC30V series Variable Speed Drive
Local Network with a DHCP Server
For the AC30, the parameter 0929 DHCP must be set to
TRUE (see the section Automatically Assigning an IP
Address using DHCP).
Local Network without a DHCP Server
Devices on the network either:
• Use fixed addresses, in which case the parameters
0929 DHCP and 0930 Auto IP must be set to
FALSE (see the section Manually Setting the IP
Address), or
• Use link-local addresses, in which case the
parameter 0930 Auto IP must be set to TRUE (see
the section Automatically Assigning an IP Address
using Auto-IP).
DHCP
Server
Switch
Switch
www.comoso.com

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
