C-7 Compliance
AC30V series Variable Speed Drive
Standard EN 61800-3
Frame G
Frame H
Frame H
Frame J
Conducted emissions
Category C1
Not suitable for use in this
environment
Not suitable for use in this
environment
Not suitable for use in this
environment
Not suitable for use in this
environment
Category C2
When fitted with an internal filter
Maximum cable length 10 m
When fitted with an internal filter
Maximum cable length 10 m
When fitted with the specified external
filter & EMC filter kit, refer to C17
Maximum cable length 25 m
Please contact Parker for more
information
Category C3
Where I<=100A
When fitted with an internal filter
Maximum cable length 50 m
When fitted with an internal filter
Maximum cable length 50 m
When fitted with an internal filter
Maximum cable length 50 m
n / a
Category C3
Where I>=100A
---- ----
When fitted with an internal filter
Maximum cable length 50 m
Standard build
Maximum cable length 50 m
Radiated
Emissions
When mounted inside a cubicle with the required attenuation between:
Not Applicable
30-1000MHz at 10dB
No specific enclosure required
Cable Requirements
Power Supply
From all other wiring (clean)
Motor Cable
From all other wiring (noisy)
External Filter
to Drive
From all other wiring (noisy)
Brake Resistor
From all other wiring (noisy)
Signal/Control
From all other wiring (sensitive)
