Parker AC30 series User Manual

C-37 Compliance
AC30V series Variable Speed Drive
FRAME G Terminal acceptance range: 16-4 AWG
Model Number
Power Input AWG
Power Output AWG
Brake Output / DC AWG
400V Build Variant: 380-480V ±10%
NORMAL
DUTY
31V-4G0045-.. 6 6 8
31V-4G0060-.. 4 4 6
31V-4G0073-.. 3 3 4
HEAVY
DUTY
31V-4G0045-.. 8 8 8
31V-4G0060-.. 6 6 6
31V-4G0073-.. 4 4 4
FRAME H
Model Number
Power Input AWG
Power Output AWG
Brake Output / DC AWG
400V Build Variant: 380-480V ±10%
NORMAL
DUTY
31V-4H0087-.. 4 2 3
31V-4H0105-.. 3 1/0 2
31V-4H0145-.. 1 3/0 1/0
HEAVY
DUTY
31V-4H0087-.. 6 3 3
31V-4H0105-.. 4 2 2
31V-4H0145-.. 3 1/0 1/0
FRAME J
Model Number
Power Input AWG
Power Output AWG
Brake Output / DC AWG
4
00V Build Variant: 380-480V ±10%
NORMAL
DUTY
31V-4J0180-.. 2/0 4/0 3/0
31V-4J0205-.. 4/0 250kcmil 4/0
31V-4J0260-.. 250 kcmil 350 kcmil 300 kcmil
HEAVY
DUTY
31V-4J0180-.. 3/0 4/0 3/0
31V-4J0502-.. 4/0 300 kcmil 4/0
31V-4J0260.. 300 kcmil 400 kcmil 300kcmil
www.comoso.com

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
