Parker AC30 series User Manual

D-80 Parameter Reference
AC30V series Variable Speed Drive
PNO Parameter Descriptions
Crossing zero speed
Torque ON
Open Loop
Closed loop
Speed setpoint (2)
Current setpoint (3)
Startup speed
0.75 * Startup speed
Startup current
Speed input (1)
Startup current
0.75 * Startup speed
Startup speed
Ramp (4)
Startup
time
(5)
(1) : User speed setpoint
(2) : Internal speed setpoint
(3) ; Internal current setpoint
(
4) : ramps are generated based on ramp parameters
(5
) : startup procedure : a current is smoothly installed into the motor
(6) : zero crossing for the speed input : the current must be inverted into the motor
www.comoso.com

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
