Parker AC30 series - Page 356

D-84 Parameter Reference
AC30V series Variable Speed Drive
PNO Parameter Descriptions
Select 1
This is connected to a Digital Input as part of the selected macro. It provides bit 1 of the Selected Preset number.
Select 2
This is connected to a Digital Input as part of the selected macro. It provides bit 2 of the Selected Preset number.
Functional Description
Select 2 Select 1 Select 0 Selected Preset
FALSE FALSE FALSE Preset Speed 0
FALSE
FALSE
TRUE
Preset Speed 1
FALSE
TRUE
FALSE
Preset Speed 2
FALSE
FALSE
FALSE
Preset Speed 3
TRUE
FALSE
TRUE
Preset Speed 4
TRUE
TRUE
FALSE
Preset Speed 5
TRUE
FALSE
FALSE
Preset Speed 6
TRUE
FALSE
FALSE
Preset Speed 7
