D-88 Parameter Reference
AC30V series Variable Speed Drive
Functional Description
The table below describes how Output is controlled by Raise Input, Lower Input and Reset Input.
Reset
Raise Input
Raise Output
Action
TRUE
Any
Any
Output tracks Reset Value
FALSE
TRUE
FALSE
Output ramps up to Maximum Value at Ramp Time
FALSE
FALSE
TRUE
Output ramps down to Minimum Value at Ramp Time
FALSE
FALSE
FALSE
Output not changed. *
FALSE
TRUE
TRUE
Output not changed. *
* If Output is greater than Maximum Value the Output will ramp down to Maximum Value at Ramp Time. If Output is less than
Minimum Value the Output will ramp up to Minimum Value at Ramp Time.
IMPORTANT:
If Maximum Value is less than or equal to Minimum Value, then Output is set to Maximum Value.
