Parker AC30 series User Manual

Parameter Reference D-151
AC30V series Variable Speed Drive
PNO
Name
Path(s)
Type
Default
Range
Units
WQ
View
Notes
MBus
1430
Warranty Trips Record.22 VDC RIPPLE
Parameters::Trips::Trips History
BOOL
NEVER
ENGINEER
1
03387
1441
Anout 01 ABS
Setup::Inputs and Outputs::Base IO
Parameters::Inputs And Outputs::IO Configure
BOOL FALSE ALWAYS OPERATOR
03409
1442
Recent Trip Times
Parameters::Trips::Trips History
ARRAY[0..9]
NEVER
ENGINEER
03411
1443
Recent Trip Times[0]
Parameters::Trips::Trips History
UDINT
0 to Max
s
NEVER
ENGINEER
1
03413
1444
Recent Trip Times[1]
Parameters::Trips::Trips History
UDINT
0 to Max
s
NEVER
ENGINEER
1
03415
1445
Recent Trip Times[2]
Parameters::Trips::Trips History
UDINT
0 to Max
s
NEVER
ENGINEER
1
03417
1446
Recent Trip Times[3]
Parameters::Trips::Trips History
UDINT
0 to Max
s
NEVER
ENGINEER
1
03419
1447
Recent Trip Times[4]
Parameters::Trips::Trips History
UDINT
0 to Max
s
NEVER
ENGINEER
1
03421
1448
Recent Trip Times[5]
Parameters::Trips::Trips History
UDINT
0 to Max
s
NEVER
ENGINEER
1
03423
1449
Recent Trip Times[6]
Parameters::Trips::Trips History
UDINT
0 to Max
s
NEVER
ENGINEER
1
03425
1450
Recent Trip Times[7]
Parameters::Trips::Trips History
UDINT
0 to Max
s
NEVER
ENGINEER
1
03427
1451
Recent Trip Times[8]
Parameters::Trips::Trips History
UDINT
0 to Max
s
NEVER
ENGINEER
1
03429
1452
Recent Trip Times[9]
Parameters::Trips::Trips History
UDINT
0 to Max
s
NEVER
ENGINEER
1
03431
1458
Modbus Conn Timeout
Parameters::Base Comms::Modbus
TIME
66.000
0.000 to 100000.000
s
ALWAYS
TECHNICIAN
03443
1459
Max Spd when Autotuned
Parameters::Motor Control::Autotune
REAL
x.
-1 to 100000
RPM
NEVER
ENGINEER
3,6
03445
1460
Anout 02 Scale
Same as PNO 1441
REAL
1.0000
Min to Max
ALWAYS
OPERATOR
03447
1461
Anin 11 Offset
Setup::Inputs and Outputs::Option
Parameters::Option IO::General Purpose IO
REAL 0.00 Min to Max % ALWAYS OPERATOR
03449
1462
Anin 11 Scale
Same as PNO 1461
REAL
1.0000
Min to Max
ALWAYS
OPERATOR
03451
1463
Anin 12 Offset
Same as PNO 1461
REAL
0.00
Min to Max
%
ALWAYS
OPERATOR
03453
1464
Anin 12 Scale
Same as PNO 1461
REAL
1.0000
Min to Max
ALWAYS
OPERATOR
03455
1465
Anin 13 Offset
Same as PNO 1461
REAL
0.00
Min to Max
%
ALWAYS
OPERATOR
03457
1466
Anin 13 Scale
Same as PNO 1461
REAL
1.0000
Min to Max
ALWAYS
OPERATOR
03459
1467
Anout 02 Offset
Same as PNO 1441
REAL
0.00
Min to Max
%
ALWAYS
OPERATOR
03461
1468
Anout 02 ABS
Same as PNO 1441
BOOL
FALSE
ALWAYS
OPERATOR
03463
1469
AR Enable
Setup::Motor Control::Auto Restart
Parameters::Motor Control::Auto Restart
BOOL FALSE ALWAYS OPERATOR
03465
1470
AR Mode Same as PNO 1469
USINT
(enum)
1
0:TRIP RESET
1:AUTO RESTART
2:AUTO START
ALWAYS OPERATOR
03467
1471
AR Max Restarts
Same as PNO 1469
USINT
10
1 to 20
ALWAYS
OPERATOR
03469
