Promise Technology Smartstor NS4600 User Manual

SmartStor NS4600 Product Manual
104
The backed up files will appear on the NAS in a folder named
BACKUPDATA_your username.
You can also click the Start button to run a scheduled backup immediately.
Viewing Backup Schedules
To view the list of current schedules:
1. Go to the Main Window.
2. Click the SmartSYNC icon.
3. Click the Schedule List button.
The list of all backup schedules appears.
Changing a Scheduled Backup
You can schedule backups by the hour, day, or week.
To change the scheduled backup of files from your PC to the NAS system
(SmartNAVI):
1. Go to the Main Window.
2. Click the SmartSYNC icon. (A)
3. Click the Schedule List button. (B)
4. Click the schedule you want to change. (C)

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
