Promise Technology Smartstor NS4600 User Manual

Chapter 7: Troubleshooting
311
4. Click the Check File System button.
5. In the confirmation box, type yes into the field provided, then click the OK
button.
During the File System Check or Rebuild, the System Status LED blinks
amber and the Disk Activity LEDs blink blue. See page 307, Figure 1.
The time needed to check and rebuild the File System depends on the
amount of data on the SmartStor. The process can take anywhere from 10
minutes to 2 hours.
Checking the Event Log in PASM
To view the Event Log in PASM:
To check Enclosure status:
1. Start PASM.
See “PASM in your Browser” on page 193.
Or see “PASM in SmartNAVI” on page 194.
Or see “PASM in Bonjour” on page 196.
2. Click the Administration topic and choose the Management icon to expand
the Tree.
3. In the Tree, click the Event Log icon.
The Event Log displays. See Figure 4.
Warning
Do not disconnect the power or shut down the SmartStor while the
check/rebuild is running!

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
