SmartStor NS4600 Product Manual
218
6. Click the OK button in the confirmation box.
You can now access the folder you chose from a UNIX or Linux PC.
See “Chapter 3: Connecting to the SmartStor” on page 31 for information
about the settings that you must make on your UNIX or Linux PC.
Setting up Mac Access
Setting up Mac Service
The Mac tab enables you to activate the Mac service for the SmartStor.
With the Mac service, Mac computer users can access the from the network and
use it for data storage.
To set up access from a Mac:
1. Click the Administration topic and choose the File & Print icon to expand
the Tree. (A)
2. Click the Protocol Control icon (B), then click the Mac tab. (C)
3. Click the Enable button (D).
4. Optional. Type a message in the Login Message field. (E)
5. Click the OK button to save your settings. (F)
The optional login message appears on the Welcome screen when you log
into SmartStor from a Mac.

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
