Promise Technology Smartstor NS4600 User Manual

SmartStor NS4600 Product Manual
250
2. If you chose Daily, select the time of day from the menus.
If you chose Weekly, select the day of the week and time of day from the
menus.
3. Click the OK button.
Replication will occur automatically as scheduled.
Setting eSATA Backup
The eSATA Backup tab enables you to change the backup services of the
SmartStor and the eSATA storage device.
To set the eSATA Backup settings:
1. Click the Backup Services you want.
• Backup data from the eSATA storage device to Share Folder
• Backup data from Share Folder to the eSATA storage device
2. Select a Backup Method you want from the drop-down list.
• Add Directory
•Copy
• Synchronize
3. Select a Folder Name you want from the drop-down list.

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
