Promise Technology Smartstor NS4600 User Manual

SmartStor NS4600 Product Manual
58
Setting-up Apple iTunes
The Firefly Media Server plug-in enables SmartStor to be a shared resource in
the Apple iTunes user interface. You must perform the setup operation on the PC
where you installed SmartNAVI.
Downloading the Firefly Plug-in
To download the Firefly Media Server plug-in:
1. Download your Firefly plug-in from the Promise Support Website.
Plug-in file names end with a .ppg extension.
2. Save the plug-in file to a convenient place on your PC.
Installing the Firefly Plug-in
To install the Firefly Media Server plug-in using
SmartNAVI:
1. Double-click the SmartNAVI icon in the Windows
application tray or Mac Dock (right)
The SmartNAVI Window opens.
2. Double-click the system in the NAS List.
SmartNAVI in
Windows
SmartNAVI in
Mac OS X

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
